Fire Retardant Panels BS1D0

This plywood is specially treated to achieve fire classification BS1D0. The surfaces can be lacquered, oiled, painted, brushed to produce the design according to customer’s needs.

Option 1: treated core birch plywood, veneer/stain of your choice

Option 2: core cement-bounded particle board, veneer of your choice

 Perforated Fire retardant Panels can also be used as Acoustic panels

Euroclass Classification

Class Material Description Performance description Flashover
A1 Non flammable No contribution to fire Over 20 minutes to flashover
A2 Non flammable No contribution to fire Over 20 minutes to flashover
B Flammable Very limited contribution to fire Over 20 minutes to flashover
C Flammable Limited contribution to fire Between 10 and 20 minutes to flash over
D Flammable Acceptable Contribution to fire Between 10 and 20 minutes to flash over
E Flammable Acceptable Contribution to fire Less than 2 minutes to flashover
F Flammable No performance requirements Less than 2 minutes to flashover



Flaming Droplets Classification

D0 No flaming droplets
D1 No flaming droplets that persist for less than 10 seconds
D2 Flaming droplets

  Smoke Classification

S1 Low Smoke
S2 Medium Smoke
S3 High Smoke

Treated Plywood V.S. Normal Plywood                                                   Treated Perforated Plywood V.S. Normal Perforated Plywood

Treated Plywood V.S. Normal Plywood

Treated Perforated Plywood V.S. Normal Perforated Plywood



For more information about surface treatment, please check coloring and veneering page.

Panels produced by Technomar & Adrem can be used as Wall or Ceiling Panels depending on the fixing profile used. For more information please visit installation guide.
